Emergency Exit Button
Fireproof Material Resetable Fire Alarm Switch Call Point with Cover
- Model Number: EX008-C
- Max. Voltage: 3A 36VDC Max
- Feature: Reset automatically,open & close
- Output contact: NO/NC/COM
Features
Product Name: Resetable Switch Call Point with Dual LED
Dimensions: 90Lx93Wx45H(mm)
Material: ABS, PC (transparent part)
Surface: Surface Mount
Standard Structure: Fireproof Material, Easy to install
Operation current: DC 12V/18mA(Standby)/75mA(Operation) (±5%) DC 24V/11mA(Standby)/41mA(Operation) (±5%)
Output: N.O.N.C.&COM. Output(Maximum load of 125V/3A)
Color: Red,White,Green,Orange, Yellow,Black,Blue etc
OEM & ODM Support customized
Unit Weight: 0.2KG
Standard Package: 100PCS/carton
Carton Weight: 20KG
Carton Size: 50*45*24(cm)
